Maxime_ecn slow build / TP4070-V1 / Reisenauer 6:1 / 12S li-ion / VESC 100A / Horue Foil

tp power 4070 and motor chief

Peter & Silvio had nice success with this setup so hopefully it will be okay. If not i will go for direct drive

I had also good success with it, even with 7 inch prop. My brother still runs it, third season still no crash​:wink::v:
Direct drive, though is much more silent.

No problem with my tpmotor 4070 and chief :wink::+1:
And I was running 8s , high pitch prop FR and no current control so really not in the best config …
still has the highest top speed achived …
Really happy with my FR direct drive , but I was thinking redo this step up in 12s for fun … now that I have a good vesc

Its a high rpm setup and gearbox gets a lot of hot the problem starts inisde the pinions bearings and continue with the principal bearing, I will remove this parts for ceramic and cooper parts, I was riding this propulsion 4 months.
my advice direct system or 5870 tp power+ motor chief, more torque and less rpm.

Its my experience ok?


Main bearing , pretty staff … and very hard to remove and put back in the gear holder , I don’t recommend to do that

Running 3200rpm max , about 60H not problem with the needles bearing so far

I took it a part because I glued the prop shaft and I had to heat it to take it off , and didn’t want to heat the bearing, but I shouldn’t have done that at the time …

I think the problem is the plastic inside the pinions, when this part is in bad condition, the system gets very hot and the main bearing is damaged, well, my idea is to change these plastic bearings and place the bronze bearings, I think which supports high temperatures and more rpm, I will test it soon and share, about the main bearing, I will try this ceramic link, its width of 9 mm. I will build a piece of aluminum to complete it. I love this propulsion for surfi, is smooth and powerful at the same time


check the value for Cr and Cor … vs the 6002
bronze bearings is a nice idea

Thanks for your comments guys. I think it will work, let’s see how long :joy: but your gearbox looks really nice after 60H @Alexandre
I have the 3 pignon version so i guess it will be less durable…

My flipsky 200A vesc is on his way, now i need to build the battery.

I found this spot welder on Aliexpress, do you think it’s worth it to buy something like this ? :

1 Like

It’s been a while i didn’t post. I’m making slow progress… now i have everything i need for a 12S12P. And this came in the mail today, Kweld spotwelder :

First test gave me some really good results, it was worth the money compared to the chinese sunkko crap welder.

Now it’s time to build the battery :slight_smile:

1 Like

Hello, It available for 30EUR for 90cm (70EUR for Anodiset). Asking yesterday.

1 Like

Battery is done, it was a lot of work… now the question is : should i use it for discharge or charge only? I don’t want it to fail like it happened before on my eskate…

Most guys used BMS only for charge. If you asking about BMS.

I use it for charge AND discharge and work very well. By my side, I have work 8 years on battery and it’s a lot safer!

If it has a high amp rating then you can use it on discharge too! Id slap an aluminum heatsink on it to keep it cool when riding hard. I’ve been using mine to charge and discharge without any issues so far (24s 150a Smart BMS).

Thanks for your answers. Yes it’s high amp rating (320A) so i can use it without any problem. What are the risks of not using a BMS for discharge ? i guess it’s to avoid over discharge on the cells but if i properly set the minimum voltage on my VESC is it not enough ? I have 12S so i will set my VESC to cut at 36V (3V per cell)

Been using vesc without bms for 1 year without issue with (safe) good settings. But now i am using 150A rated bms for 6 months and i am very happy With it, managing balancing and settings with bluetooth is a must have ( also can set temp cutoff and so on)
I even did 1hour and half rides without issues. Never had to test the overcurrent function hopefully :wink:

Hi. Some news of my build :

I finished the battery with integrated BMS and then I realized something strange : you can turn on the BMS but there is no way to turn it off. If you want to turn it off, you need to do it in the Bluetooth app, and turning off will also reset to factory settings. So if you don’t turn it off, the BMS stays in “stand by” mode, and i’m not really confident about it. I don’t want to risk a BMS failure when the battery is in the house or in my van so i decided to remove the BMS. I will use 2 voltage controller instead (with alarm) when riding.

When i removed the BMS i realized that my cable connections were not great. That’s how i did it first, with double 10AWG cables :

I want to do it better.I still have some 6AWG and a roll of flat copper wire. I had a little test to solder them together :

I tried to pull as hard as i can and it looks like the soldering is strong enough.
My plan is then to solder the copper band on all the battery lenght like this :

I need advice from the battery experts on this forum. Do you think it’s a nice and safe way to do it ?

1 Like

Few weeks ago were similar discussion about BMS and someone proposed to use some on/off switch.
Check this thread for example

and this thread also:

From what i’ve seen in datasheets the braided copper sleeves have really low copper area - it’s basicly 40 somewhat very thin wires and a million crossings.

Therefore I think your 2xawg10 is probably higher area. You should check this.

Also your connections will not be 100% balanced due to the voltage drop from first to last parallell group on the connection line. If you don’t run super high battery currents like +300A i’d not worry about this though.
