jeffM · March 2, 2021, 4:21pm

02/03/2021 Prop and gong wing test
I didn’t finish my V4 Efoil, So I tested the new props and Wings with My V3.
First test : old wing configuration (curve XL) and new prop Flite

1 amp less than my alu prop and no more noise very happy
so 16A with this configuration

Second test : same wing, new alu melted prop

unfortunately 20A

3 test : prop flite, wing gong veloce XXL stab 47cm veloce

consumption 14A

and final test : prop flite, wing gong Veloce XL, stab 47CM veloce
consumption 17A/ 18A, but I increase the speed, and stability is better than XXL veloce

So for my mew V4 Efoil I 'll used the Veloce VS curve and the prop Flite with the cone is my better prop until now.
I’ll began a new thread for the construction of my V4 soon

coulpi · March 2, 2021, 5:03pm

And the contact between carbon and aluminum is not a problem ?

Toto44 · March 2, 2021, 6:58pm

What speed you get at 18A with Veloce xl.

coulpi · March 5, 2021, 4:25pm

Thanks
And what is thickness of alu cover ?

max36 · March 10, 2021, 8:22am

Hello JeffM.

Nice job!! How do you power on your board ? By plugging your magnetic switch? Do you have an extra switch like an antispark one ?

philippe · March 10, 2021, 10:46am

Hello
what do you use as a pump for cooling, thanks

jeffM · March 11, 2021, 10:33am

See upper on the parts list, you have the link on aliexpress

jeffM · March 11, 2021, 10:36am

max36
=> yes I plug the magnetic switch to power on, I have only an connector XT90S
like that

You can see upper, you have the schematics

jeffM · March 11, 2021, 10:39am

Coupli
=> thickness of alu cover = 2mm
and no pb with alu and carbone, but I use it only on a lake

jeffM · March 11, 2021, 10:42am

toto44
=> at 18A with veloce XL 22-24km/H

Toto44 · March 11, 2021, 10:45am

that is increduíble low consuption! Nearly cant believe it. How do you measure amps?

coulpi · March 16, 2021, 2:45pm

Hello

Are you some cad or fusion 360 files of your board ?

jeffM · March 16, 2021, 3:30pm

Hi Pierre,
No sorry I shaped the board directly in a foam “styrodur” without CAD file

coulpi · March 22, 2021, 12:22am

Hi , where do you find the app of bms ?

coulpi · April 3, 2021, 6:36am

Hi, how do you turn on the battery ?

jeffM · April 3, 2021, 7:15am

You can find the APP on apple store : " AMT BMS"
There is a switch on the BMS for turning ON the battery
and you can turn off with the software

coulpi · April 3, 2021, 7:30am

Thanks , but to turn on , you must open then battery box ?

jeffM · April 3, 2021, 8:06am

Yes
that why it’s différente for my V4 :
I can start the BMS by plug the charge connector (and the charge connector is outside the battery box ).

jeffM · April 4, 2021, 5:56pm

Efoil V3 Monteynard april 2021

Alexandre · April 4, 2021, 9:24pm

Really like this place , need to try someday , nice video and built
